Mounting

The SSP 200 can be set on a table, mounted on a rack shelf, or mounted under a desk,
podium, or table.
ATTENTION:

Tabletop Placement

Attach the four provided rubber feet to the bottom of the unit and place it in any convenient
location.

Rack Mounting

See the Extron
SSP 200. Follow the instructions provided with the kit.
UL Guidelines for Rack Mounting
The following Underwriters Laboratories (UL) guidelines are relevant to the safe installation of
these products in a rack:
1.
2.
3.
4.
5.

Under-desk Mounting

See the Extron
SSP 200. Follow the instructions provided with the kit.
• Installation and service must be performed by authorized personnel only.
• L'installation et l'entretien doivent être effectués uniquement par un technicien
qualifié.
website
for a list of optional rack mounting kits that are suitable for the
Elevated operating ambient temperature — If the unit is installed in a closed or
multi-unit rack assembly, the operating ambient temperature of the rack environment
may be greater than room ambient temperature. Therefore, install the equipment in
an environment compatible with the maximum ambient temperature (Tma: +122° F,
+50° C) specified by Extron.
Reduced air flow — Install the equipment in the rack so that the equipment gets
adequate air flow for safe operation.
Mechanical loading — Mount the equipment in the rack so that uneven mechanical
loading does not create a hazardous condition.
Circuit overloading — Connect the equipment to the supply circuit and consider the
effect that circuit overloading might have on overcurrent protection and supply wiring.
Appropriate consideration of the equipment nameplate ratings should be used when
addressing this concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to supply connections other than direct connections
to the branch circuit (such as the use of power strips).
website
to find the optional under-desk mounting kit that is suitable for the
