ATTENTION:
Valid firmware files must have the file extension .eff. A file with any other
•
extension is not a firmware upgrade for this product and could cause the
SSP 200 to stop functioning.
Les fichiers firmware valides doivent contenir l'extension fichier .eff. Un fichier
•
avec n'importe quelle autre extension n'est pas une mise à jour de firmware
pour cet appareil et l'appareil pourrait arrêter de fonctionner.
12. Click Open or double‑click the firmware file.
13. Click Update on the Update Firmware dialog box (see figure 61). This uploads and
verifies the new firmware onto the connected device. The Installing Firmware
progress field shows the progress of the upload.
Figure 61. Update Firmware
14.
After the upload is complete, a dialog box opens confirming that the update has been
successful. Click Close. The software returns to the Device Discovery window (see
figure 55 on page 59).
15. Select the SSP 200 from the Device Discovery menu. A connection must be
re‑established with the device before continuing to use the software.
16. Click Connect, or double‑click the device. The device reconnects to the software.
NOTE: The original factory‑installed firmware is permanently available on the
SSP 200. If the attempted firmware upload fails for any reason, the device reverts
to the factory version.
SSP 200 • Product Configuration Software 61
