4. Scroll down the page until you locate the firmware for the SSP 200.
5. Click Download. The product download screen opens.
6. Enter the required user login information. An executable (.exe) file downloads to the PC.
Run this program to place the firmware on the PC. Make a note of the folder where the
firmware file was saved.
ATTENTION:
•
•
Loading the Firmware to the SSP 200
To load a new version of firmware to the SSP 200 using PCS:
1. Connect your computer to the SSP 200 via either the device rear RS‑232 or LAN port
(see Rear Panel Features
(see Front Panel Features
2. If needed, download and install PCS to your computer (see
the Extron Website
3. If needed, download the latest version of SSP 200 firmware to your computer (see
Downloading the SSP 200 Firmware
4. Open PCS by clicking the desktop icon, if available or using your desktop Start menu
to make the following selections: Start > All Programs > Extron Electronics >
Extron Product Configuration Software.
The Product Configuration Software window opens to the Device Discovery
screen (see figure 55).
Figure 55.
On the Device Discovery screen, select the SSP 200 (
5.
6. Click Connect (
7. The Product Configuration Software opens to the main page (see figure 56). Click
the device menu arrow next to the name of the device (
Figure 56.
The extension of the firmware file must be .eff. Opening a file with an incorrect
extension may cause the device to stop functioning.
L'extension du fichier firmware doit être .eff. Si un fichier est ouvert avec une
mauvaise extension, l'appareil peut arrêter de fonctionner.
starting on page 6) or the front panel USB Config port
starting on page 11).
on page 29).
1 1 1
SSP 200
PCS Device Discovery Screen
).
2
Accessing the Device PCS Menu
Downloading PCS from
on page 58).
192.168.254.254 SSP 200
2 2 2
).
1
).
1
SSP 200 • Product Configuration Software 59
