Figure 44.
Center and Outer Handles
To modify Q (Parametric filters):
In the Filter dialog box, select the filter to be modified. To do so, either click the filter
1.
number to the left of Filter menu or click the appropriate Frequency handle below the
graph.
2.
Click and drag one of the Q handles within the graph, located at the lower or upper
frequency on the filter curve, left or right to the desired position or value.
Alternatively, enter the value in the Q field for the selected filter, or click the up or down
arrows next to the field until the desired value is displayed.
EQ Filter Copy and Paste
Copy and Paste buttons are available to streamline your repeat filter settings. The buttons
are located at the bottom right of the page.
Figure 45.
EQ Filter Copy and Paste Buttons
To copy and paste a setting:
1.
Click a number to select filter settings to copy.
2.
Click the Copy (
) button.
3.
Click a different filter number to paste.
4.
Click the Paste (
) button.
SSP 200 • Product Configuration Software
49
