Dolby Digital Source Formats

These include inputs 1 to 4 only.
Dolby Digital (2/0, 2/0 Surround, 5.1, Surround EX)
Dolby Digital is a flexible, discrete, digital technology for carrying multi‑channel audio. Dolby
Digital supports up to six discrete audio channels; five full range front and surround channels
and a band‑limited LFE (Low frequency effects) subwoofer channel. Most legacy Dolby
Digital formats are supported by the SSP 200 including ProLogic (I & II), EX, and 2.0. Dolby
Digital formats are 16‑bit with up to 48 kHz sampling.
When the SSP 200 detects this source format the Dolby
formats, the 2-CH LED is lit.
Dolby Digital Plus/Dolby Digital Plus Atmos
Dolby Digital Plus and Dolby Digital Plus Atmos are extensions of Dolby Digital with a higher
bit rate and channel count. Dolby Digital Plus supports up to eight discrete audio channels
plus encoded channels including Dolby Atmos immersive Height (ceiling) channels. The
SSP 200 supports up to 12 total output channels. This is the preferred format for most
streaming services.
When this source format is present, the Dolby
detected within the Dolby Digital Plus bitstream, the ATMOS LED is also lit.
Dolby TrueHD/Dolby TrueHD Atmos
Dolby TrueHD is a variable bitrate lossless codec, capable of supporting up to eight
full‑range channels (7.1) of 24‑bit audio at 96 kHz. Just like Dolby Digital Plus, TrueHD
Atmos content is encoded in the discrete channels. TrueHD formats offer the highest
quality audio experience.
When this source format is present, the Dolby
within the TrueHD bitstream, the ATMOS LED is also lit.

DTS Source Formats (DTS)

These include inputs 1 to 4 only, unless otherwise noted.
DTS/DTS 96/24
Like Dolby Digital, DTS is a flexible, discrete, digital technology for carrying multi‑channel
audio. DTS supports up to six discrete audio channels; five full range front and surround
channels and a band limited LFE (Low frequency effects) subwoofer channel. All DTS
formats have 24‑bit depth, which allows more audio information to be stored compared
with the normal 16‑bit depth. DTS 96/24 formats improve audio further by using the 96 kHz
sampling frequency instead of the standard 48 kHz.
When this source format is present, the DTS LED is lit.
DTS ES (96/24, Matrix, Discrete)
Similar to standard 5.1 DTS formats, DTS ES (DTS Extended Surround) includes an
additional Back channel. This sixth channel allows the user to configure mono back
speakers or split it for a 7.1 configuration.
When this source format is present, the DTS LED is lit.
LED is lit. For stereo only
LED is lit. If Dolby Atmos content is
LED is lit. If Atmos content is detected
SSP 200 • Reference 25
