Basic Jack Operation In Manual Mode

To reach Manual Mode (Fig. 15) for leveling:
1.
While in Standard Mode (Fig. 11), use the arrows (Fig. 11G) to scroll to "Manual Mode" (Fig. 11E). Press
"ENTER" (Fig. 11B).
2.
Front and rear jacks can be operated in Manual Mode. The Power Tongue Jack cannot be operated in
Manual Mode.

OneControl Touch Panel App In Standard and Manual Modes

Standard Mode Features
• "EXTEND" (Fig. 11I) or "RETRACT" (Fig. 11H) and "FRONT" (Fig. 11A) extends or retracts the Power Tongue
Jack.
• "AUTO LEVEL" (Fig. 11J) button starts the auto leveling sequence.
• "AUTO HITCH" (Fig. 11K) button starts the hitch recognition sequence when reconnecting to the tow vehicle.
• Use the "UP" or "DOWN" arrow (Fig. 11G) buttons to cycle through the menu screen options:
– Info: Scroll to "Info" (Fig. 11C) and press "ENTER" (Fig. 11B) button to display system information, e.g.,
angle, jack stroke or software version.
– Auto Retract: Scroll to "Auto Retract" (Fig. 11D) and press "Enter" button to start the "Auto Retract"
sequence, which will retract all jacks. The Power Tongue Jack does not retract.
– Manual Mode: Scroll to "Manual Mode" (Fig. 11E) and press "Enter" button to start manual leveling
process.
Manual Mode Features
Upon entering Manual Mode, a tutorial on operating the jacks will appear on the screen. Press "OK" to clear
the tutorial. To delete the tutorial, click the "Don't show this again" box in the bottom right of the screen.
NOTE: The jacks operate in pairs. If at any time in manual mode the jacks operate individually, the Twist
Protection Prevention System has been activated to prevent frame twist. The OneControl Touch
Panel or OneControl App will display "Relieving frame twist." The jacks will resume operating in pairs
when the potential frame twist has been relieved.
Press "EXTEND" (Fig. 15F) or "RETRACT" (Fig. 15E) and "FRONT" (Fig. 15B) to operate front jacks.
Press "Extend" or "Retract" and "REAR" (Fig. 15D) operate rear jacks.
Press "Extend" or "Retract" and "RIGHT" (Fig. 15C) operate right jacks.
Press "Extend" or "Retract" and "LEFT" (Fig. 15A) operate left jacks.
NOTE: To operate jacks individually, press "EXTEND" or "RETRACT" then press the "LEFT" (Fig. 15A) or
"RIGHT" (Fig. 15C) button while simultaneously pressing the "Front" (Fig. 15B) or "Rear" button (Fig.
15D), depending on which jack needs to be operated.
NOTE: If the jacks will not operate individually as intended, but they operate properly when Auto Level is
performed, the Twist Prevention Protection system has locked out the operation to prevent damage
to the frame of the trailer.
Rev:11.08.19
Fig. 1 5 Manual Mode
B
A C
D
E F
