GROUND CONTROL

System Information

Ground Control 3.0 is an automatic leveling system for 5th wheel applications. The system utilizes one main
control board and a separate waterproof remote level sensor to measure and manage level point, and can be
operated from several user interface devices, including:
Auto Leveling Control Touch Pad - Mounted outside the trailer within view of the hitch.
MyRV® OneControl™ Touch Panel (OCTP) - Mounted on a wall inside the living space of the trailer.
MyRV® OneControl™ Leveling App - The app is available on iTunes® for iPhone® and iPad® and also on Google
Play™ for Android™ users. iTunes®, iPhone® and iPad® are registered trademarks of Apple Inc. Google Play™ and An-
droid™ are trademarks of Google Inc.
Linc® Remote Control - Optional.
NOTE: Ground Control 3.0 IS FOR 5TH WHEEL APPLICATIONS ONLY.
Lippert Components Inc. recommends that a trained professional be employed to change the tires on the trailer.
Ensure that the trailer is properly supported with jack stands or other adequate devices under the frame of the
trailer prior to commencing any service or repair procedure. Any attempts to change the tires or perform other
service while trailer is supported solely by the Ground Control 3.0 jacks could

Touch Pad Diagram - Auto Leveling Control Touch Pad

Callout Description
A Red/Green LED - Indicates the status of the system.
B Up Arrow - Extends front jacks (landing gear).
C Down Arrow - Retracts front jacks (landing gear).
D Auto Level Button - Places leveling system into auto level mode.
E Hitch Height Button - Initiates the Hitch Recognition feature.
F Retract All Button - Places leveling system into full retract mode.
Rev: 11.08.19
3.0 ONECONTROL™ TOUCH PANEL
®
LEVELING AND STABILIZATION
result in death, serious injury, trailer or property damage.
B
C
Fig. 1
A
D
To turn on the touch pad, press the
Up and Down arrow buttons at the
same time.
Page 25
E
F
CCD-0001573-08
