Error Display Screen - OneControl Touch Panel/App.

NOTE: Errors can only be cleared via the OneControl Touch Panel (Fig. 4) or the OneControl App. The only
exception is when the Auto Leveling Control Touch Pad (Fig. 3) was used to abort an auto sequence.
In this case, the error can be cleared by pressing any Auto Leveling control button. Correct Error to
clear it, then press "OK." If Error persists, message will continue to display.
LCD Message
"EXCESS ANGLE"
"EXCESSIVE ANGLE"
"BAD CALIBRATION"
"FEATURE DISABLED"
"LOW VOLTAGE"
"OUT OF STROKE"
"EXTERNAL SENSOR"
"JACK TIME OUT"
"AUTO LEVEL FAILURE"
"FUNCTION ABORTED"
"HALL POWER SHORT"
"CAN'T COMPLETE
LEVEL IN THIS
LOCATION. PLEASE
RELOCATE RV TO
FLATTER TERRAIN"
Rev:11.08.19
What Is Happening?
Unsecured sensor.
Uneven or sloped site.
Sensor not properly secured.
Excessive angle reached during
manual operation.
Trailer Zero Point was not set
correctly.
Hitch recognition requested but no
hitch height set.
Zero Point not set.
Bad connection or wiring.
Discharged or bad battery.
Unsecured controller.
Uneven or sloped site.
Bad connection or wiring.
System could not level in expected
time.
Unsecured controller.
Voltage drop.
User has aborted an automatic
leveling sequence.
Short circuit detected on one or more
of the 5K jack power lines.
The trailer is parked on a steep incline
during auto level. The front cannot
be leveled and the front jacks are
already fully retracted.
What Should Be Done?
Check and secure sensor placement.
Relocate the trailer.
Check and secure sensor placement.
Relocate the trailer.
Reset Zero Point. See "Zero Point
Calibration" section.
Perform "AUTO LEVEL" sequence to
establish hitch height.
Set Zero Point. See "Zero Point Calibration"
section.
Check wiring - repair or replace.
Test battery voltage under load - charge or
replace.
Check and secure controller placement.
Relocate the trailer.
Replace or repair connection to rear remote
sensor.
Check for obstructions, leaks, fluid level and
voltage to power unit motor under load.
Check and secure controller placement.
Test battery voltage under load - charge or
replace.
Restart the sequence.
Check harness and replace or repair.
Relocate the trailer.
