Extending Landing Gear

1.
Extend both landing gear to the ground by pulling the
quick release bolt-on pull pins (Fig. 1).
NOTE: If the front of the trailer is above level, do not extend the
inner legs to the ground. The trailer cannot be leveled if
the front is already above level when released from the
tow vehicle.
2.
Make sure the bolt-on pull pins are re-engaged with the
landing gear leg.
3. Push EXT (extend) side of the LANDING LEGS CONTROL
switch (Fig. 2).
4.
Unhook trailer from tow vehicle.
5. Push and hold the EXT button to raise the landing gear to
desired height.

Retracting Landing Gear

1.
Push RET (retract) side of LANDING LEGS CONTROL switch
(Fig. 2).
2.
Lower trailer onto tow vehicle.
3.
Once trailer is secured, make sure the trailer is latched.
4. Press and hold the RET button to fully retract both landing
gear.
NOTE: Be sure to hold down the switch until both landing gear
are fully retracted before pulling the bolt-on pull pins.
5.
Pull the bolt-on pull pins and slide the inner legs into the
outer landing gear legs.
6.
Make sure the bolt-on pull pins are re-engaged upon
completion.
NOTE: In the event the landing gear becomes out of sync, fully
retract them to resynchronize the landing gear.

Troubleshooting

What Is Happening?
Landing gear out of sync
Difficulty leveling trailer
Switch does not activate
landing gear
Rev:11.08.19
What Should Be Done?
Fully retract landing gear to synchronize.
If front of trailer is above level, do not extend inner legs to the ground.
Test battery voltage under load. Charge or replace.
Check wiring. Repair or replace.
Page 135
Fig. 1
Footpad
Snapper
Pin
Fig. 2
Bolt-
On
Pull
Pin
