Reconnecting to Tow Vehicle

1.
Chock the tires of the trailer.
2.
Press "EXT" (Fig. 2C) if needed to allow the coupler to clear the hitch ball.
3. Push "RET" (Fig. 2B) to retract the Power Tongue Jack until the coupler properly mounts the hitch ball
and the leg.
4.
Latch the tow vehicle hitch and connect any wires, chains or sway control that may be equipped
between the tow vehicle and trailer.
5. Press "RET" two times and hold on the third time approximately 5 seconds until the Power Tongue Jack
pauses. Let go of the switch and the Power Tongue Jack will automatically retract.
6.
Be sure the leg of the Power Tongue Jack (Fig. 1A) is fully retracted prior to moving the tow vehicle.

Touch Pad Diagram - Auto Leveling Control Touch Pad

B
C
Callout Description
A Red/Green LED - Indicates the status of the system.
B Up Arrow - Extends Power Tongue Jack .
C Down Arrow - Retracts Power Tongue Jack.
D AUTO LEVEL Button - Places leveling system into auto level mode.
E HITCH HEIGHT Button - Initiates the Hitch Recognition feature.
RETRACT ALL Button - Places leveling system into full retract mode. Power Tongue Jack does
F
not retract.

Operation - Auto Leveling Control Touch Pad

Basic Power Tongue Jack Operation

1. To turn on the touch pad, press both "UP" and "DOWN" arrows (Fig. 3B and 3C) at the same time. The
green indicator LED (Fig. 3A) will turn "On".
2.
Press the "UP" arrow (Fig. 3B) to extend the Power Tongue Jack and lift the front of trailer to take the
weight of the trailer off of the hitch.
3.
Press the "DOWN" arrow (Fig. 3C) to retract the Power Tongue Jack.
Rev:11.08.19
Fig. 3
A
D
To turn on the touch pad, press the UP and
DOWN arrow buttons at the same time.
Page 53
E
F
CCD-0001573-08
