Auxiliary Operation

The Lippert Hydraulic Landing Gear can be run with power devices like electric drills or cordless screwdrivers. In
the event of electrical or system failure, this manual method of extending and retracting the jacks can be used. A
standard hand-held cordless or power drill is all that is required.
1.
Locate the blocking valve (Fig. 1) on the top cap of either of the landing gear jacks.
5/32
2. Using a " Allen wrench, manually open the valve by turning the manual override set screw in the
end of the valve clockwise (Fig. 1).
3.
Remove protective label from the motor (Fig. 2).
4.
Using a standard
hex bit into coupler found under protective label (Fig. 2).
5.
Run drill forward or clockwise to retract jacks and in reverse or counterclockwise to extend jacks.
6.
Be sure to turn manual override set screw back to the counterclockwise position after extending or
retracting landing gear (Fig. 3).
Rev:11.08.19
1/4
" hex bit, insert into auxiliary drive device, i.e. cordless drill or power drill. Insert
Fig. 1
Fig. 3
Page 102
Fig. 2
CCD-0001573-08
