15. ABOUT THE DV GATEWAY FUNCTION
Troubleshooting

DTroubleshooting for the Access Point mode operation

The following chart is designed to help you correct problems which are not equipment malfunctions.
If you are unable to locate the cause of a problem or solve it through the use of this chart, contact your
Icom Dealer or Service Center.
Problem
After your call, the repeater
does not return a status reply.
(No S-meter indication)
After your call, the repeater
replies "UR?," the Access
Point call sign and ID suffix
"G."
Possible Cause
The wrong Access Point mode
transceiver is selected in the
Remote D-STAR transceiver.
The manually entered frequency
or duplex setting is wrong in the
Remote D-STAR transceiver.
The transmission from the Remote
D-STAR transceiver did not reach
the Access Point mode transceiver.
Transceiver connection is wrong.
The Remote D-STAR transceiver's
call sign has not been added
to "Allowed Call Sign List" in
the transceiver, RS-MS3W, or
RS-MS3A, when "Allowed Call
Sign" is set to "Enable."
When using the External Gateway
function, you did not click (touch)
<Start> in the RS-MS3W or
RS-MS3A.
The call was successfully sent to
the Access Point, but no station
immediately replied.
15-24
Solution
Set "FROM" to the correct Access
Point mode transceiver.
Set the correct frequency or
duplex setting.
Move to a place where the
Remote D-STAR transceiver can
reach the Access Point mode
transceiver.
When using the Internal Gateway
function, check the connection
between the transceiver and the
router.
When using the External Gateway
function, check the connection
between the transceiver and the
Windows or Android device.
When using the Internal Gateway
function, add the Remote D-STAR
transceiver's call sign to "Allowed
Call Sign List" in the INTERNAL
GATEWAY SETTINGS screen.
When using the External Gateway
function, add the Remote D-STAR
transceiver's call sign to "Allowed
Call Sign List" in the RS-MS3W or
RS-MS3A.
Click (touch) <Start>
RS-MS3W or RS-MS3A.
Wait for a while, and try again.
REF�
–
–
–
p. 15-10
pp. 15-12,
15-13
p. 15-11
RS-MS3W,
RS-MS3A's
instruction
manual
in the
–
