15. ABOUT THE DV GATEWAY FUNCTION
Troubleshooting

DTroubleshooting for the Terminal mode operation

The following chart is designed to help you correct problems which are not equipment malfunctions.
If you are unable to locate the cause of a problem or solve it through the use of this chart, contact your
Icom Dealer or Service Center.
Problem
After your call, the repeater
does not return a status reply.
After your call, the repeater
replies "UR?," Your own call
sign (MY) and ID suffix "G."
After your call, the repeater
replies "RX" or "RPT?" and
Your own call sign (MY) and
ID suffix "G."
Possible Cause
Transceiver connection is wrong.
"Allowed Call Sign" is set to
"Enable."
When using the External Gateway
function, you did not click (touch)
<Start> in the RS-MS3W or
RS-MS3A.
The call was successfully sent, but
no station immediately replied.
Your call sign (MY) has not been
registered at a gateway server.
The Terminal/AP call sign that is
set in the transceiver, RS-MS3A, or
RS-MS3W has not been registered
in the RS-RP3C as the access
point.
The destination station's call sign
(UR) has not been registered to the
gateway server, or the registered
contents do not match your
transceiver's setting.
The destination station that uses
the Terminal mode or Access Point
mode does not transmit periodically.
15-22
Solution
When using the Internal Gateway
function, check the connection
between the transceiver and the
router.
When using the External Gateway
function, check the connection
between the transceiver and the
Windows or the Android device.
When using the Internal Gateway
function, set "Allowed Call Sign"
to "Disable" in the INTERNAL
GATEWAY SETTINGS screen.
When using the External Gateway
function, set "Allowed Call sign"
to "Disable" in the RS-MS3W or
RS-MS3A.
Click (touch) <Start>
RS-MS3W or RS-MS3A.
Wait for a while, and try again.
Register your call sign (MY) at a
gateway server.
When using the Internal Gateway
function, register the Terminal/
AP call sign that is set in the
transceiver in the RS-RP3C as the
access point.
When using the External Gateway
function, register the Terminal/
AP call sign that is set in the
RS-MS3A or RS-MS3W in the RS-
RP3C as the access point.
Check the destination station's
register information.
The destination station makes a
call again.
REF�
p. 15-10
pp. 15-12,
15-13
p. 15-10
RS-MS3W,
RS-MS3A's
instruction
manual
in the
–
–
p. 13-4
p. 13-4
–
–
