12. GPS OPERATION (ADVANCED)
GPS SET
Data Extension
Selects whether or not to transmit the Course/
Speed data or the Power/Hight/Gain/Directivity
data with the position data in the D-PRS mode.
LThe number of characters you can enter in
"Comment" differs, depending on the "Altitude" and
"Data Extension" settings.
• OFF: Does not transmit any
information.
• Course/Speed: Transmits the course and
speed data with the position
data.
• Power/Height/Gain/Directivity:
Transmits the TX power level,
height, antenna gain, and
antenna direction, along with
the position data.
Course
Sets the Object's course to between 0º and 360º.
LThis item is displayed when "Data Extension" is set
to "Course/Speed."
Speed
Sets the Object's speed to between 0 and
1150 mph.*
* If the Speed unit is set to "km/h," set to between 0 to
1850 km/h, or set to "knots," set to between 0 and
999 knots.
LThis item is displayed when "Data Extension" is set
to "Course/Speed."
Power
Selects the TX power level of Object, to transmit
along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select 0, 1, 4, 9, 16, 25, 36, 49, 64, or 81 W.
Height
Selects the height of the Object's antenna, to
transmit along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select 10, 20, 40, 80, 160, 320, 640, 1280,
2560, or 5120 feet.*
* If the Altitude/Distance unit is set to "m," select 3, 6,
12, 24, 49, 98, 195, 390, 780, or 1561 meters.
(Default: OFF)
(Default: 0º)
(Default: 0mph)
(Default: 0W)
(Default: 10ft)
12-36
Gain
Selects the gain of the Object's antenna, to
transmit along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select between 0 and 9 dB.
Directivity
Selects the direction the Object's antenna was
pointing, to transmit along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select Omni, 45º NE, 90º E, 135º SE, 180ºS,
225º SW, 270º W, 315º NW, or 360º N.
SSID
Selects an SSID based on APRS
your call sign, to show your operating style to
other stations. The additional methods of the
SSID differ, depending on whether the call sign
includes a space or not.
LSee page 12-33 for details of the SSID.
• ---: The space in call sign is converted to
"-."
• (-0): No SSID is added.
• -1 ~ -15: Adds an SSID of -1 to -15 to your call
sign.
• -A ~ -Z: Adds an SSID of -A to -Z to your call
sign.
Time Stamp
Selects the transmitting time stamp type.
The time stamp is transmitted with the position
data in the D-PRS mode, and UTC (Universal
Time Coordinated) time is used.
• DHM: Transmits the time stamp in the Day,
Hour, and Minute format.
• HMS: Transmits the time stamp in the Hour,
Minute, and Second format.
(Default: 0dB)
(Default: Omni)
(Default: ---)
® to add to
(Default: OFF)
