12. GPS OPERATION (ADVANCED)
GPS SET
Speed
Sets the Item's speed to between 0 and
1150 mph.*
* If the Speed unit is set to "km/h," set to between 0 to
1850 km/h, or set to "knots," set to between 0 and
999 knots.
LThis item is displayed when "Data Extension" is set
to "Course/Speed."
Power
Selects the TX power level of Item, to transmit
along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select 0, 1, 4, 9, 16, 25, 36, 49, 64, or 81 W.
Height
Selects the height of the Item's antenna, to
transmit along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select 10, 20, 40, 80, 160, 320, 640, 1280,
2560, or 5120 feet.*
* If the Altitude/Distance unit is set to "m," select 3, 6,
12, 24, 49, 98, 195, 390, 780, or 1561 meters.
Gain
Selects the gain of the Item's antenna, to transmit
along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select between 0 and 9 dB.
Directivity
Selects the direction the Item's antenna was
pointing, to transmit along with the position data.
LThis item is displayed when "Data Extension" is set
to "Power/Height/Gain/Directivity."
• Select Omni, 45º NE, 90º E, 135º SE, 180ºS,
225º SW, 270º W, 315º NW, or 360º N.
(Default: 0mph)
(Default: 0W)
(Default: 10ft)
(Default: 0dB)
(Default: Omni)
12-38
SSID
Selects an SSID based on APRS
your call sign, to show your operating style to
other stations. The additional methods of the
SSID differ, depending on whether the call sign
includes a space or not.
LSee page 12-33 for details of the SSID.
• ---: The space in call sign is converted to
"-."
• (-0): No SSID is added.
• -1 ~ -15: Adds an SSID of -1 to -15 to your call
sign.
• -A ~ -Z: Adds an SSID of -A to -Z to your call
sign.
(Default: ---)
