14. D-STAR OPERATION (ADVANCED)
Entering new information into the repeater list
D Entering new information into the repeater list
Step 6� Entering the gateway repeater call sign
LThis item is displayed when Step 2� Selecting the
communication type is set to "DV Repeater."
LThe 8th digit in the call sign, entered in Step 5�
Entering the repeater call sign is automatically
set to "G" as the gateway port, so you can skip this
setting and go to the next item.
1. Touch "GW CALL SIGN."
2. Enter a gateway repeater call sign of up to 8
characters, including spaces.
LOnly a space or "G" can be entered in the 8th
digit.
3. After entering, touch [ENT].
Step 7� Changing the repeater group
LThe repeater group that is selected in Step 1�
Selecting the repeater group is displayed. You
can skip this setting and go to the next item. To
change the group, follow the steps, described
below.
1. Touch "GROUP."
2. Touch the repeater group. (01 ~ 50)
Step 8� Setting "USE(FROM)" to be used as
an Access repeater
LYou can use the entered repeaters as an access
repeater when using the DR function. When not
using as an access repeater, select "NO," and go
to Step 14� Selecting the position data accuracy
level. In that case, the entered repeater is not
displayed in "FROM" on the DR screen.
1. Touch "USE(FROM)."
2. Touch "YES" to use the repeater as an
access repeater.
Step 9� Entering the access repeater frequency
1. Touch "FREQUENCY."
2. Enter the repeater frequency.
3. After entering, touch [ENT].
Step 10� Selecting the Duplex direction
LWhen Step 2� Selecting the communication type
is set to "DV Simplex" or "FM Simplex," this item is
not displayed.
L"DUP–" is automatically set when the access
repeater frequency is entered in Step 9� Entering
the access repeater frequency. If necessary, you
can change the Duplex direction.
1. Touch "DUP."
2. Touch a Duplex direction.
• OFF: Turn the duplex function OFF.
• DUP–: The transmit frequency shifts down from
the receive frequency by the offset amount.
• DUP+: The transmit frequency shifts up from the
receive frequency by the offset amount.
Step 11� Entering the frequency offset
LWhen Step 2� Selecting the communication type
is set to "DV Simplex" or "FM Simplex," this item is
not displayed.
LThe offset value* is automatically set when the
access repeater frequency is entered in Step 9�
Entering the access repeater frequency. If
necessary, you can change the frequency offset.
* The default value differs, depending on the
transceiver version.
1. Touch "OFFSET FREQ."
2. Enter the frequency offset.
• Range: 0.000.00 ~ 99.999.9 MHz
3. After entering, touch [ENT].
Step 12� Setting the tone
LWhen Step 2� Selecting the communication type
is set to "DV Repeater" or "DV Simplex," this item is
not displayed.
1. Touch "TONE."
2. Touch an option.
• OFF: Turn OFF the Tone function.
• TONE: Select when the repeater requires an
access tone.
• TSQL: Select when you want to use the tone
squelch in simplex operation.
14-26
