ADC PG-Flex FLC-706 1A Technical Practice

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C
S
SCP-FLC706-011-03H
ECTION
PG-F
T
ECHNICAL
4 C
HANNEL
O
ENTRAL
FFICE
Model
List
FLC-706
1A
LEX
P
RACTICE
PG-FLEX
FLC 706
LIST
A
1
C
2
T
I
3
V
E
4
FAULT
ISDN
C
HANNEL
CLEI Code
VACHEGPC~~
U
NIT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-Flex FLC-706 1A and is the answer not in the manual?

Questions and answers

Related Manuals for ADC PG-Flex FLC-706 1A

Summary of Contents for ADC PG-Flex FLC-706 1A

  • Page 1 PG-F ECHNICAL RACTICE PG-FLEX FLC 706 LIST FAULT ISDN HANNEL ENTRAL FFICE HANNEL Model List CLEI Code FLC-706 VACHEGPC~~ SCP-FLC706-011-03H ECTION...
  • Page 2 Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable for any damages resulting from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
  • Page 3 • Unpack each container and visually inspect the contents for signs of damage. If the equipment has been damaged in transit, immediately report the extent of damage to the transportation company and to ADC. Order replacement equipment, if necessary. •...
  • Page 4 Inspecting Your Shipment SCP-FLC706-011-03H January 6, 2003 FLC-706 List 1A...

  • Page 5: Table Of Contents

    SCP-FLC706-011-03H ABLE OF ONTENTS Overview ____________________________________________________________________________ 1 Description and Features........................1 Operational Capabilities ......................1 Applications.........................2 Front Panel ............................3 Specifications .............................4 Installation And Test ___________________________________________________________________ 4 Integration Parameters ........................4 Installing the FLC-706 in the COT Shelf...................5 Provisioning the FLC-706 ....................5 Verify operation........................5 Outgoing calls........................5 lncoming calls........................6 Troubleshooting _______________________________________________________________________ 7...
  • Page 6 SCP-FLC706-011-03H January 6, 2003 FLC-706 List 1A...
  • Page 7 SCP-FLC706-011-03H IST OF IGURES 1. Typical ISDN Configuration ...........................2 2. FLC-706 ISDN Channel Unit Front Panel ......................3 FLC-706 List 1A January 6, 2003...
  • Page 8 SCP-FLC706-011-03H January 6, 2003 FLC-706 List 1A...
  • Page 9 SCP-FLC706-011-03H IST OF ABLES 1. FLC-706 Front Panel LEDs..........................3 2. COT Channel Unit Troubleshooting ........................7 FLC-706 List 1A January 6, 2003...
  • Page 10 SCP-FLC706-011-03H January 6, 2003 FLC-706 List 1A...

  • Page 11: Overview

    Description and Features VERVIEW ® ® The ADC PG-Flex FLC-706 List 1A ISDN Basic Rate Interface Central Office Channel Unit provides an interface to North American ISDN Basic Access services through a PG-Flex COT shelf. The FLC-706 accommodates four ISDN channels and provides ISDN Line Unit Network Termination (LUNT) at the COT shelf.

  • Page 12: Applications

    Description and Features SCP-FLC706-011-03H Applications ISDN is a networking standard that provides end-to-end, simultaneous handling of digitized voice and data traffic on the same link. Figure 1 shows a typical ISDN configuration. The FLC-706 connects an ISDN Digital Subscriber Line (DSL) to the Central Office (CO). Line Termination (LT) in the CO occurs at the ISDN switch. The DSL loops are U-interface.

  • Page 13: Front Panel

    SCP-FLC706-011-03H Front Panel RONT ANEL The front panel LEDs indicate the state of the FLC-706 (see Figure PG-FLEX FLC 706 LIST Status LEDs FAULT Retaining Latch Figure 2. FLC-706 ISDN Channel Unit Front Panel Each LED for the four channels has the same states and indications. Table 1.

  • Page 14: Specifications

    Specifications SCP-FLC706-011-03H PECIFICATIONS Transmission Code 2B1Q, 2 binary, one quaternary, at 160 kbps Network Interface 3DS0 format Basic Rate Interface 2B+D; 2 B channels at 64 kbps, one D channel at 16 kbps Ω dc Resistive Test Signature 120 k Ω...

  • Page 15: Installing The Flc-706 In The Cot Shelf

    SCP-FLC706-011-03H Installing the FLC-706 in the COT Shelf FLC-706 COT S NSTALLING THE IN THE HELF Insert the FLC-706 into the COT shelf. Ensure the LEDs go through the following sequencing: • turn ON for about 2 seconds • turn OFF for about 2 seconds •...

  • Page 16: Lncoming Calls

    Installing the FLC-706 in the COT Shelf SCP-FLC706-011-03H lncoming calls Verify incoming calls for both B channels, for example, calls from the LT to the NT1 (refer to Figure 1 on page To test an incoming B1 voice call: draw dial tone from another ISDN or POTS circuit dial the ISDN B1 voice circuit number verify that the number you called is displayed (when answered) verify that the number from which you called is displayed as the originating number...

  • Page 17: Troubleshooting

    SCP-FLC706-011-03H Installing the FLC-706 in the COT Shelf ROUBLESHOOTING Table 2 provides troubleshooting procedures using the front panel LEDs and customer reports. The FLC-706 supports CO initiated loopbacks. Table 2. COT Channel Unit Troubleshooting LEDs State Indicates Action FAULT Fault detected in the PG-Flex Replace channel unit.

  • Page 18: Product Support

    ADC’s Return Material Authorization (RMA) Department. Call or write ADC’s RMA Department to ask for an RMA number and any additional instructions. Use the telephone number, fax number or email address listed below: •...
  • Page 19 If there is another reason for returning the equipment, please let us know so we can determine how best to help you. Pack the equipment in a shipping carton. Write ADC’s address and the RMA Number you received from the RMA Department clearly on the outside of the carton and return to: ADC DSL Systems, Inc.

  • Page 20: Fcc Classa Compliance

    The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by ADC Technologies, Inc. voids the user's warranty. All wiring external to the product(s) should follow the provisions of the current edition of the National Electrical Code.

  • Page 21: Acronyms

    SCP-FLC706-011-03H Modifications CRONYMS Bit Error Rate BERT Bit Error Rate Test Central Office COLU Central Office Line Unit Central Office Terminal Digital Subscriber Line Embedded Operations Channel ISDN Integrated Services Digital Network LPBK Loop Back LULT Line Unit Line Termination LUNT Line Unit Network Termination Mechanized Loop Testing...
