At Command Response Frame - 0X88 - Digi XBee 3 ZigBee User Manual

Frame descriptions

AT Command Response frame - 0x88

Description
A device sends this frame in response to an AT Command (0x08 or 0x09) frame. Some commands send
back multiple frames; for example, the ND command.
Format
The following table provides the contents of the frame. For details on frame structure, see
format.
Frame data
fields Offset Description
Frame type 3
Frame ID 4
AT 5-6
command
Command 7
status
Command
data
Example
If you change the BD parameter on a local device with a frame ID of 0x01, and the parameter is valid,
the user receives the following response.
Frame data
fields
Start delimiter
Length
Frame type
Frame ID
Digi XBee® 3 Zigbee® RF Module
0x88
The FrameID used in the original AT Command request frame will be
populated in the corresponding response. If the FrameID in the AT Command
request was 0, then no response will be generated.
Command name: two ASCII characters that identify the command.
0 = OK
1 = ERROR
2 = Invalid command
3 = Invalid parameter
4 = Tx failure
The register data in binary format. If the host sets the register, the device
does not return this field.
Offset Example
0 0x7E
MSB 1 0x00
LSB 2 0x05
3 0x88
4 0x01
AT Command Response frame - 0x88
