Digi XBee 3 ZigBee User Manual page 260

Frame descriptions
Frame data
fields
Options
RF data
Example
The example shows how to send a transmission to a device if you disable escaping (AP = 1), with
destination address 0x0013A200 40014011, and payload "TxData1B".
Frame data fields
Start delimiter
Length
Frame type
Frame ID
64-bit destination
address
16-bit destination
network address
Broadcast radius
Options
Digi XBee® 3 Zigbee® RF Module
Offset Description
Bitfield of supported transmission options. Supported values include the
16
following:
0x01 - Disable retries
0x20 - Enable APS encryption (if EE=1)
0x40 - Use the extended transmission timeout for this destination
Enabling APS encryption decreases the maximum number of RF payload
bytes by 4 (below the value reported by NP).
Setting the extended timeout bit causes the stack to set the extended
transmission timeout for the destination address. See
addressing, and routing.
All unused and unsupported bits must be set to 0.
17-n Data sent to the destination device.
Transmit Request frame - 0x10
Offset Example
0 0x7E
MSB 1 0x00
LSB 2 0x16
3 0x10
4 0x01
MSB 5 0x00
6 0x13
7 0xA2
8 0x00
9 0x40
10 0x0A
11 0x01
LSB 12 0x27
0xFF
MSB 13
0xFE
LSB 14
15 0x00
16 0x00
Transmission,
