Digi XBee 3 ZigBee User Manual page 310

Status Transparent
code mode string Description
0x20 FormNetwork Forming a network
- parameters
Discovering
0x21 Looking for Key Establishment Endpoint
KE Endpoint
KE Endpoint
0x22 Found Key Establishment Endpoint
The following example shows a successful association with Verbose Join enabled in AT Command mode.
Note Comments are included with the trace messages to explain the content and are preceded by an ellipsis "...".
+++OK
atid3151 OK
...configured pan identifier has been changed atdc10
OK
...and verbose join enabled atac
OK
...applying changes to the configuration V AI - Searching for Parent:FF
...search has started
V AI - Searching for Parent:FF
...and started again
Status data Description
radioChannel channel number ranging form 11 to 26
(1)
radioTxPower low level radio transmit power setting
(1)
panid(2) 16 bit PAN identifier for network
extendedpanid 64 bit PAN identifier for network
(8)
Endpoint(1) Endpoint number
