D3 (Dio3/Ad3/Th_Spi_Ssel Configuration); D4 (Dio4/Th_Spi_Mosi Configuration) - Digi XBee 3 ZigBee User Manual

AT commands
Parameter
0
1
2
3
4
5
Default
0

D3 (DIO3/AD3/TH_SPI_SSEL Configuration)

Sets or displays the DIO3/AD3 configuration (Micro pin 28/SMT pin 30/TH pin 17).
Parameter range
SMT/MMT: 0, 2 - 5
TH: 0 - 5
Parameter
0
1
2
3
4
5
Default
0

D4 (DIO4/TH_SPI_MOSI Configuration)

Sets or displays the DIO4 configuration (Micro pin 23/SMT pin 24/TH pin 11).
Parameter range
SMT/MMT: 0, 3 - 5
TH: 0, 1, 3 - 5
Digi XBee® 3 Zigbee® RF Module
Description
Disabled
SPI_CLK for through-hole devices
N/A for surface-mount devices
ADC
Digital input
Digital output, low
Digital output, high
Description
Disabled
SPI_SSEL for the through-hole device
N/A for surface-mount device
ADC
Digital input
Digital output, low
Digital output, high
I/O settings commands
216
