Digi XBee3 Cellular LTE-M Cellular Module Patch and Maintenance Release via EasyFlash Firmware Update
Digi XBee3 Cellular LTE-M Cellular Module Patch and
Maintenance Release via EasyFlash Firmware
Update
This document describes how to update the cellular modem firmware of the XBee3 Cellular LTE-M
module using EasyFlash and the XBIB-CU-TH development board.
It applies to the XBee3 Cellular device containing the following cellular modem:
u-blox SARA-R410M-02B
n
There are two .zip packages available to update the u-blox module via EasyFlash. You must contact
Digi Technical Support to get both of these .zip packages.
Critical issue patch (required): Version L0.0.00.00.05.06-A02.01 patch
n
This is a required patch to fix a critical issue as described here:
Issue on XBee3 Cat M
Maintenance release (recommended): Version L0.0.00.00.05.08 maintenance release
n

Prerequisites

Firmware requirements:
n
For the critical issue patch: XBee3 Cellular LTE-M with firmware 1140A or above
l
For the maintenance release: XBee3 Cellular LTE-M with firmware 11413 or above
l
Valid SIM installed
n
XBIB-CU-TH Development board
n
XCTU-NG latest release version (6.4.3 or later)
n
EasyFlash version 10.02
n
USB 3.0 port (supports required current)
n
USB-C cable
n
USB-B micro cable
n
Guides for installing EasyFlash 10.02 and required drivers:
n
SARA-R4 Firmware Update R2.pdf
l
SARA-R4 USB Driver Installation.pdf
l

Precautions

For best results:
The update operation should have exclusive access to the XBee. Disable any running
n
MicroPython scripts or other communication to the module.
90002353_C
Cellular.
u-blox Memory Housekeeping
