Digi XBee 3 ZigBee User Manual page 309

Status Transparent
code mode string Description
0x0F Join Request High level request for a form/join.
0x10 Reject LQI Reject because LQI is worse than an already
saved beacon
0x11 Reject RSSI Rejected because RSSI is worse than an
already saved beacon
0x12 Rejected Rejected because it matches the last
(cmdL ast) associated network.
0x13 Rejected Rejected because it matches an already saved
(cmdS ave) beacon response.
0x14 Reject During first/best phase, response is weaker
strength than an already saved beacon response.
0x16 Reset for With DC80 enabled, reset if no joinable beacon
DC80 responses are received within 60s of joining.
0x18 ScanCh Scanning on Channel
0x19 Scan Mode Shows phase of Ordered Association.
0x1A Scan Init Starting a scan
0x1D Energy Scan - Starting energy scan
channel mask
0x1E Energy Scan - Channel Energies observed
energies
0x1F PanIdScan - Pan Id Scan starting on channel
radio channel
Status data Description
lqi(1) link quality indicator
rssi(1) relative signal strength indicator
radioChannel channel number ranging from 11 to 26 (0x0B to 0x1A)
(1)
0: first/bestcandidate
mode(1)
1: ordered association by extpanid, then by channel
channel being scanned
channel(1)
low level radio transmit power setting
TxPower(1)
SC mask(4)
Scan channel mask
Energy Levels per channel in SC
Energies(16)
channel(1) Radio Channel
