Send Zigbee cluster library (ZCL) commands with the API

The Zigbee cluster library defines a set of attributes and commands (clusters) that can be supported
in multiple Zigbee profiles. The ZCL commands are typically required when developing a Zigbee
product that will interoperate in a public profile such as home automation or smart energy, or when
communicating with Zigbee devices from other vendors. Applications that are not designed for a
public profile or for interoperability applications can skip this section.
The following table shows some prominent clusters with their respective attributes and commands.
Cluster (Cluster ID)
Basic (0x0000)
Identify (0x0003)
Time (0x000A)
Thermostat (0x0201)
The ZCL defines a number of profile-wide commands that can be supported on any profile, also known
as general commands. These commands include the following.
Digi XBee® 3 Zigbee® RF Module
Send Zigbee cluster library (ZCL) commands with the API
Attributes (Attribute ID)
Application Version (0x0001)
Hardware Version (0x0003)
Model Identifier (0x0005)
Identify Time (0x0000)
Time (0x0000)
Time Status (0x0001)
Time Zone (0x0002)
Local Temperature (0x0000)
Occupancy (0x0002)
Offset Example
0xFF
MSB 13
0xFE
LSB 14
15 0x00
16 0x00
17 0x00
18 0x05
19 0x00
20 0x00
21 0x00
22 0x00
23 0x01
24 0x34
25 0x12
29 0xA6
Cluster ID
Reset to defaults (0x00)
Identify (0x00)
Identify Query (0x01)
Setpoint raise / lower (0x00)
