V, $W, $X, $Y Commands (Srp Salt Verifier); Sleep Commands; Sm (Sleep Mode) - Digi XBee 3 ZigBee User Manual

AT commands
Note The XBee 3 Zigbee RF Module does not allow for 0 to be valid salt. If the value is 0, SRP is
disabled and you are not able to authenticate using Bluetooth.
Parameter range
0 - FFFFFFFF
Default
0
$V, $W, $X, $Y commands (SRP Salt verifier)
Use the $V, $W, $X, and $Y verifiers in conjunction with
for the XBee 3 Zigbee RF Module. Together, $S and the verifiers authenticate the client for the BLE API
Service without storing the XBee password on the XBee device.
Configure the salt with the $S command. In the $V, $W, $X, and $Y verifiers, you specify the 128-byte
verifier value, where each command represents 32 bytes of the total 128-byte verifier value.
Parameter range
0 - FFFFFFFF
Default
0

Sleep commands

The following commands enable and configure the low power sleep modes of the device.

SM (Sleep Mode)

Sets or displays the sleep mode of the device.
When SM > 0, the device operates as an end device. However, CE must be 0 before SM can be set to a
value greater than 0 to change the device to an end device. Changing a device from a router to an end
device (or vice versa) forces the device to leave the network and attempt to join as the new device
type when changes are applied.
Parameter range
0, 1, 4, 5
Parameter Description
0 Sleep disabled (router)
1 Pin hibernate
2 N/A
3 N/A
4 Cyclic sleep enabled
Digi XBee® 3 Zigbee® RF Module
$S (SRP Salt) to create an encrypted password
Sleep commands
211
