Digi XBee 3 ZigBee User Manual page 304

Frame descriptions
Frame data fields
64-bit destination address
Session Options
Timeout
Checksum
Secure Session status code descriptions
Status Description
0x3B A Secure Session was
established with this
node
0x3C A Secure Session
ended
Digi XBee® 3 Zigbee® RF Module
Data
(length) Description
Address The address of the client in the session.
(8)
Options Session options set by the client.
(1)
Timeout Session timeout set by the client.
(2)
Address The address of the other node in this session.
(8)
Reason The reason the session was ended:
0x00 - Session was terminated by the other node
(1)
0x01 - Session Timed out
0x02 - Received a transmission with an invalid
encryption counter
0x03 - Encryption counter overflow - the maximum
number of transmissions for a single session has been
reached
0x04 - Remote node out of memory
Extended Modem Status frame - 0x98
Offset Example
MSB 4 0x00
5 0x00
6 0x00
7 0x00
8 0x00
9 0x00
10 0x00
LSB11 0x00
12 0x00
13 0x15
14 0x54
23 0x97
304
