Digi XBee 3 ZigBee User Manual page 314

Frame descriptions
Format
The following table provides the contents of the frame. For details on frame structure, see
format.
Frame
data
fields Offset Description
Frame 3
type
Frame ID 4
Status 5
Example
A device is registered to the trust center using a 0x24 frame with a Frame ID of 0x53. The following
status is returned, indicating that the registration was a success.
Frame data fields
Start delimiter
Length
Frame type
Frame ID
Status
Checksum
Digi XBee® 3 Zigbee® RF Module
0xA4 Register Device Status
Identifies the data frame for the host to correlate with a subsequent response.
It matches the Frame ID of the registration request (0x24).
0x00 = Success
0x01 = Key too long
0xB1 = Address not found in the key table
0xB2 = Key is invalid (00 and FF are reserved)
0xB3 = Invalid address
0xB4 = Key table is full
0xFF = Key not found
Offset
0
MSB 1
LSB 2
3
4
5
6
Register Device Status - 0xA4
API frame
Example
0x7E
0x00
0x03
0xA4
0x53
0x00 (Success)
0x08
314
