Verbose Join status code descriptions

The following table describes the various Verbose Join trace messages in Status Code order. The Transparent mode string column shows the string which
appears if you run Verbose Join in Command mode. The Description column gives a more detailed explanation of each particular message. When a
message accompanies Status Data, the Status Data column shows how to parse the hexadecimal string into fields. The number of bytes per field appears
in parentheses "()".
Status Transparent
code mode string Description
0x00 Rejoin A join attempt is being started.
0x01 Stack Status Shows status and state.
Status data Description
rejoinState(1) The rejoinState is a count of join attempts.
0x00 - no network
Status(1)
0x01 - joining
0x02 - joined
0x03 - joined (no parent)
0x04 - leaving
0x90 - Network is up and ready to receive/transmit.
NetworkStat e
0x91 - Network is down and cannot receive/transmit.
(1)
0x94 - Join attempt failed.
0x96 - A node's attempt to re-establish contact with the
network after moving failed.
0x98 - A join attempt as a router failed due to a Zigbee 2006
versus Zigbee PRO 2007 incompatibility. Try to join as an end
device.
0x99 - The network ID has changed.
0x9A - The PAN ID has changed.
0x9B - The channel has changed.
0xAB - No beacons were received in response to a beacon
request.
