Over-the-air firmware/file system upgrade process for Zigbee 3.0
Frame data fields
Data ZCL frame
payload header
ZCL payload
Checksum

Upgrade End response

If the server receives an Upgrade End request with a SUCCESS status, it generates an Upgrade End
response along with the time at which the device should upgrade to the new image.
Frame data fields
Start delimiter
Length
Frame Type
Frame ID
Digi XBee® 3 Zigbee® RF Module
Frame control
Transaction sequence
number
Command ID
Status
Manufacturer ID
Image type
Firmware version
Offset Example Comments
0
MSB 1 0x00
LSB 2 0x24
3
4
Upgrade End response
Offset Example Comments
21 0x01
22 0x30
23 0x06 Upgrade End Request
24 0x00 Success = 0x00
Invalid Image = 0x96
Abort = 0x95
Require More Image =
0x99
LSB 0x1E
25
MSB 0x10
26
LSB 0x00 0x0000 - OTA/OTB file
0x0100 - OTA file system
27
MSB 0x00
28
LSB 0x01
29
30 0x10
31 0x00
MSB 0x00
32
38 0x3B
0x7E
0x11
0x01
