Manage End Devices
Command Range
SP 0x20 - 0xAF0 (x 10 ms)
(320 - 28,000 ms)
SN
1 - 0xFFFF
SO
0 - 0xFF
The device supports both a
commands. These two modes allow the sleep period to be configured according to the application
requirements.
Short cyclic sleep
In short cyclic sleep mode, define the sleep behavior of the device by the SP and SN commands, and
the SO command must be set to 0x00 (default) or 0x02. In short cyclic sleep mode, the SP command
defines the sleep period and you can set it for up to 28 seconds. When the device enters short cyclic
sleep, it remains in a low power state until the SP time has expired.
After the sleep period expires, the XBee 3 Zigbee RF Module sends a poll request transmission to its
parent to determine if the parent has any buffered data waiting for the end device. Since router and
coordinator devices can buffer data for end device children up to 30 seconds, the SP range (up to 28
seconds) allows the end device to poll regularly enough to receive buffered data. If the parent has
data for the end device, the end device starts its sleep timer (ST) and continues polling every 100 ms
to receive data. If the end device wakes and finds that its parent has no data for it, the end device can
return to sleep immediately.
Use the SN command to control when the On/Sleep line is asserted (high). If you SN to 1 (default), the
On/Sleep line sets high each time the device wakes from sleep. Otherwise, if SN is greater than 1, the
On/ Sleep line only sets high if RF data is received, or after SN wake cycles occur. This allows an
external device to remain powered off until it receives RF data, or until a number of sleep periods have
expired (SN sleep periods). This mechanism allows the device to wake at regular intervals to poll its
parent for data without waking an external device for an extended time (SP * SN time) as shown in
the following figure.
Digi XBee® 3 Zigbee® RF Module
Description
Configures the sleep period of the device.
Configures the number of sleep periods multiplier.
Defines options for sleep mode behavior.
0x02 - Always wake for full ST time
0x04 - Enable extended sleep (sleep for full (SP * SN) time)
Short cyclic sleep and an Extended cyclic sleep
End Device configuration
that make use of these
