Danfoss VLT AQUA Instruction Manual page 118

5 How to program the adjustable frequency
drive
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
[2117] Ext. 1 Reference [Unit]
[2118] Ext. 1 Feedback [Unit]
[2119] Ext. 1 Output [%]
[2137] Ext. 2 Reference [Unit]
[2138] Ext. 2 Feedback [Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference [Unit]
[2158] Ext. 3 Feedback [Unit]
[2159] Ext. Output [%]
5
[2230] No-Flow Power
[2580] Cascade Status
[2581] Pump Status
[2791] Cascade Reference
[2792] % Of Total Capacity
[2793] Cascade Option Status
NOTE!
Please consult the
0-21 Display Line 1.2 Small
Option:
[1662] * Analog input 53
0-22 Display Line 1.3 Small
Option:
[1614] * Motor Current
0-23 Display Line 2 Large
Option:
[1615] * Frequency
0-24 Display Line 3 Large
Option:
[1652] * Feedback [Unit]
5-12
Shows the value of the signal applied to terminal X42/7 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/9 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
The value of the reference for extended Closed-loop Controller 1
The value of the feedback signal for extended Closed-loop Controller 1
The value of the output from extended Closed-loop Controller 1
The value of the reference for extended Closed-loop Controller 2
The value of the feedback signal for extended Closed-loop Controller 2
The value of the output from extended Closed-loop Controller 2
The value of the reference for extended Closed-loop Controller 3
The value of the feedback signal for extended Closed-loop Controller 3
The value of the output from extended Closed-loop Controller 3
The calculated No-Flow Power for the actual operating speed
Status for the operation of the cascade controller
Status for the operation of each individual pump controlled by the cascade controller
Reference output for use with follower drives.
Readout parameter to show the system operating point as a % capacity of total system capacity.
Readout parameter to show the status of the cascade system.
®
VLT AQUA Drive Programming Guide, MG.20.OX.YY
Function:
Select a variable for display in line 1, middle position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 1, right position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 2. The options are the same as those listed for par. 0-20
Line 1.1 Small
.
Function:
Select a variable for display in line 2. The options are the same as those listed for par. 0-20
Line 1.1 Small .
MG.20.P3.22 - VLT
VLT AQUA High Power Instruction Manual
for detailed information.
Display Line 1.1 Small
Display Line 1.1 Small
®
