VLT AQUA High Power Instruction Manual
The quick menu parameters can be accessed immediately, unless a password has been created via par. 0-60, 0-61, 0-65 or 0-66.
It is possible to switch directly between Quick Menu mode and Main Menu mode.
[Main Menu]
is used for programming all parameters.
The main menu parameters can be accessed immediately unless a password has been created via par. 0-60, 0-61, 0-65 or 0-66. For the majority of water
and wastewater applications it is not necessary to access the main menu parameters, but instead the quick menu, quick set-up and function set-ups
provide the simplest and quickest access to the typical required parameters.
It is possible to switch directly between Main Menu mode and Quick Menu mode.
Parameter shortcut can be carried out by pressing down the
parameter.
[Alarm Log]
displays an Alarm list of the last five alarms (numbered A1-A5). For additional details on a particular alarm, use the arrow keys to navigate to the alarm
number and press [OK]. Information is displayed about the condition of the adjustable frequency drive before it enters alarm mode.
[Back]
reverts to the previous step or layer in the navigation structure.
[Cancel]
the last change or command will be canceled as long as the display has
not been changed.
Navigation Keys
The four navigation arrows are used to navigate between the different
choices available in [Quick Menu],
Use the keys to move the cursor.
[OK]
is used for choosing a parameter marked by the cursor and for enabling
the change of a parameter.
Operation Keys
for local control are found at the bottom of the control panel.
[Main Menu]
[Main Menu] and [Alarm Log].
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
4 How to operate the adjustable frequency
key for 3 seconds. The parameter shortcut allows direct access to any
[Info]
displays information about a command, parameter or function in any dis-
play window. [Info] provides detailed information when needed.
Exit Info mode by pressing either [Info], [Back] or [Cancel].
drive
4
130BP046.10
4-5
