enables control of the adjustable frequency drive via the GLCP. [Hand on] also starts the motor, and makes it possible to give the motor speed reference

using the arrow keys. The key can be

The following control signals will still be active when [Hand on] is activated:

•

[Hand on] - [Off] - [Auto on]

•

Reset

•

Coasting stop inverse (motor coasting to stop)

•

Reversing

•

Set-up select lsb - Set-up select msb

•

Stop command from serial communication

•

Quick stop

•

DC brake

NOTE!

External stop signals activated by using control signals or a serial bus will override a "start" command via the LCP.

[Off]

stops the connected motor. The key can be

[Off] key is inactive, the motor can only be stopped by disconnecting the line power supply.

[Auto On]

enables the adjustable frequency drive to be controlled via the control terminals and/or serial communication. When a start signal is applied to the control

terminals and/or the bus, the adjustable frequency drive will start. The key can be

NOTE!

An active HAND-OFF-AUTO signal via the digital inputs has higher priority than the control keys [Hand on] – [Auto on].

[Reset]

is used for resetting the adjustable frequency drive after an alarm (trip). The key can be

The parameter shortcut

can be carried out by holding down the [Main Menu] key for 3 seconds. The parameter shortcut allows direct access to any parameter.

4-6

Enabled

Disabled

0-40 [Hand on] Key on LCP.

[1] or
