Danfoss VLT AQUA Instruction Manual page 166

5 How to program the adjustable frequency
drive
5.3.15 16-** Data Readouts
Par. Parameter description
No. #
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor voltage
16-13 Frequency
16-14 Motor Current
16-15 Frequency [%]
5 16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-22 Torque [%]
16-3* Drive Status
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-5* Ref. & Feedb.
16-50 External Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-54 Feedback 1 [Unit]
16-55 Feedback 2 [Unit]
16-56 Feedback 3 [Unit]
16-58 PID Output [%]
16-59 Adjusted Setpoint
16-6* Inputs & Outputs
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Pulse Input #29 [Hz]
16-68 Pulse Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-75 Analog In X30/11
16-76 Analog In X30/12
16-77 Analog Out X30/8 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option Status
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-9* Diagnosis Readouts
16-90 Alarm Word
16-91 Alarm word 2
16-92 Warning Word
16-93 Warning word 2
16-94 Ext. Status Word
16-95 Ext. Status Word 2
16-96 Maintenance Word
5-60
Default value
0 N/A
0.000 ReferenceFeedbackUnit
0.0 %
0 N/A
0.00 %
0.00 CustomReadoutUnit
0.00 kW
0.00 hp
0.0 V
0.0 Hz
0.00 A
0.00 %
0.0 Nm
0 RPM
0 %
0 %
0 V
0.000 kW
0.000 kW
0 °C
0 %
ExpressionLimit
ExpressionLimit
0 N/A
0 °C
[0] No
0.0 N/A
0.000 ProcessCtrlUnit
0.00 N/A
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.0 %
0.000 ProcessCtrlUnit
0 N/A
[0] Current
0.000 N/A
[0] Current
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
4-set-up Change dur- Conver-
ing operation sion index
All set-ups TRUE 0
All set-ups TRUE -3
All set-ups TRUE -1
All set-ups TRUE 0
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE 1
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE -1
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE 67
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 100
All set-ups TRUE 0
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE 0
All set-ups TRUE 100
All set-ups TRUE -
All set-ups TRUE -1
All set-ups TRUE -3
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -1
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
Type
V2
Int32
Int16
V2
N2
Int32
Int32
Int32
Uint16
Uint16
Int32
N2
Int32
Int32
Uint8
Int16
Uint16
Uint32
Uint32
Uint8
Uint8
Uint32
Uint32
Uint8
Uint8
Uint8
Int16
Int32
Int16
Int32
Int32
Int32
Int16
Int32
Uint16
Uint8
Int32
Uint8
Int32
Int16
Int16
Int32
Int32
Int32
Int32
Uint16
Int32
Int32
Int32
Int32
Int16
V2
N2
V2
V2
N2
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
