5 How to program the adjustable frequency
drive
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
5
23-04 Occurrence
Array [10]
Option:
[0] * All days
[1] Working days
[2] Non-working days
[3] Monday
[4] Tuesday
[5] Wednesday
[6] Thursday
[7] Friday
[8] Saturday
[9] Sunday
5.2.12 Water Application Functions, 29-**
The group contains parameters used for monitoring water/wastewater applications.
29-00 Pipe Fill Enable
Option:
[0] * Disabled
[1] Enabled
29-01 Pipe Fill Speed [RPM]
Range:
Speed Low [Speed Low Limit - Speed High Lim-
Limit* it]
5-48
Function:
Select the day(s) to which the timed action applies. Specify working/non-working days in
Working Days Additional Working Days
par. 0-81 , par. 0-82
Days
.
Function:
Select Enabled to fill pipes at a user-specified rate.
Select Enabled to fill pipes with a user specified rate.
Function:
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM
depending on the choices made in par. 4-11 / par. 4-13 (RPM) or in par. 4-12 / par. 4-14 (Hz).
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
Additional Non-Working
and par. 0-83
