Danfoss VLT AQUA Instruction Manual page 162

5 How to program the adjustable frequency
drive
5.3.9 8-** Comm. and Options
Par. Parameter description
No. #
8-0* General Settings
8-01 Control Site
8-02 Control Source
8-03 Control Timeout Time
8-04 Control Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Timeout
8-07 Diagnosis Trigger
8-1* Control Settings
8-10 Control Profile
8-13 Configurable Status Word STW
8-14 Configurable Control Word CTW
8-3* FC Port Settings
8-30 Protocol
5
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Maximum Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram selection
8-5* Digital/Bus
8-50 Coasting Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reverse Select
8-55 Set-up Select
8-56 Preset Reference Select
8-7* BACnet
8-70 BACnet Device Instance
8-72 MS/TP Max Masters
8-73 MS/TP Max Info Frames
8-74 "Startup I am"
8-75 Initialization Password
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Message Rcvd
8-83 Slave Error Count
8-9* Bus Jog
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
8-94 Bus Feedback 1
8-95 Bus Feedback 2
8-96 Bus Feedback 3
5-56
Default value
null
null
ExpressionLimit
[0] Off
[1] Resume set-up
[0] Do not reset
[0] Disable
[0] FC profile
[1] Profile Default
[1] Profile default
null
ExpressionLimit
null
null
ExpressionLimit
ExpressionLimit
ExpressionLimit
[1] Standard telegram 1
[3] Logic OR
[3] Logic OR
[3] Logic OR
null
[3] Logic OR
[3] Logic OR
1 N/A
127 N/A
1 N/A
[0] Send at power-up
ExpressionLimit
0 N/A
0 N/A
0 N/A
0 N/A
100 RPM
200 RPM
0 N/A
0 N/A
0 N/A
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
4-set-up Change dur- Conver-
ing operation sion index
All set-ups TRUE -
All set-ups TRUE -
1 set-up TRUE -1
1 set-up TRUE -
1 set-up TRUE -
All set-ups TRUE -
2 set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
1 set-up TRUE -
1 set-up TRUE 0
1 set-up TRUE -
1 set-up TRUE -
1 set-up TRUE -3
1 set-up TRUE -3
1 set-up TRUE -5
2 set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
1 set-up TRUE 0
1 set-up TRUE 0
1 set-up TRUE 0
1 set-up TRUE -
1 set-up TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 67
All set-ups TRUE 67
1 set-up TRUE 0
1 set-up TRUE 0
1 set-up TRUE 0
Type
Uint8
Uint8
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint32
Uint8
Uint16
Uint8
VisStr[2
0]
Uint32
Uint32
Uint32
Uint32
Uint16
Uint16
N2
N2
N2
