VLT AQUA High Power Instruction Manual
5.3.16 18-** Data Readouts 2
Par. Parameter description
No. #
18-0* Maintenance Log
18-00 Maintenance Log: Item
18-01 Maintenance Log: Action
18-02 Maintenance Log: Time
18-03 Maintenance Log: Date and Time
18-3* Inputs & Outputs
18-30 Analog Input X42/1
18-31 Analog Input X42/3
18-32 Analog Input X42/5
18-33 Analog Out X42/7 [V]
18-34 Analog Out X42/9 [V]
18-35 Analog Out X42/11 [V]
5.3.17 20-** FC Closed-loop
Par. Parameter description
No. #
20-0* Feedback
20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-02 Feedback 1 Source Unit
20-03 Feedback 2 Source
20-04 Feedback 2 Conversion
20-05 Feedback 2 Source Unit
20-06 Feedback 3 Source
20-07 Feedback 3 Conversion
20-08 Feedback 3 Source Unit
20-12 Reference/Feedback Unit
20-2* Feedback/Setpoint
20-20 Feedback Function
20-21 Setpoint 1
20-22 Setpoint 2
20-23 Setpoint 3
20-7* PID Auto-tuning
20-70 Closed-loop Type
20-71 PID Performance
20-72 PID Output Change
20-73 Minimum Feedback Level
20-74 Maximum Feedback Level
20-79 PID Auto-tuning
20-8* PID Basic Settings
20-81 PID Normal/ Inverse Control
20-82 PID Start Speed [RPM]
20-83 PID Start Speed [Hz]
20-84 On Reference Bandwidth
20-9* PID Controller
20-91 PID Anti Windup
20-93 PID Proportional Gain
20-94 PID Integral Time
20-95 PID Differentiation Time
20-96 PID Diff. Gain Limit
Default value
0 N/A
0 N/A
0 s
ExpressionLimit
0.000 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0.000 N/A
Default value
[2] Analog input 54
[0] Linear
null
[0] No function
[0] Linear
null
[0] No function
[0] Linear
null
null
[4] Maximum
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
[0] Auto
[0] Normal
0.10 N/A
-999999.000 ProcessCtrlUnit
999999.000 ProcessCtrlUnit
[0] Disabled
[0] Normal
ExpressionLimit
ExpressionLimit
5 %
[1] On
2.00 N/A
8.00 s
0.00 s
5.0 N/A
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
5 How to program the adjustable frequency
4-set-up Change dur-
ing operation sion index
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
4-set-up Change dur-
ing operation sion index
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
drive
Conver- Type
0 Uint8
0 Uint8
0 Uint32
TimeOf-
0 Day
-3 Int32
-3 Int32
-3 Int32
-3 Int16
-3 Int16
5
-3 Int16
Conver- Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-3 Int32
-3 Int32
-3 Int32
- Uint8
- Uint8
-2 Uint16
-3 Int32
-3 Int32
- Uint8
- Uint8
67 Uint16
-1 Uint16
0 Uint8
- Uint8
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
5-61
