VLT AQUA High Power Instruction Manual

3 How to Install

3.1 How to Get Started

3.1.1 About How to Install
This chapter covers mechanical and electrical installations to and from power terminals and control card terminals.
Electrical installation of options is described in the relevant Instruction Manual and Design Guide.
3.1.2 How to Get Started
The adjustable frequency drive is designed for quick installation and is EMC-compliant. Just follow the steps described below.
Read the safety instructions before installing the unit.
Mechanical Installation
• Mechanical mounting
Electrical Installation
• Connection to Line and Protecting Ground
• Motor connection and cables
• Fuses and circuit breakers
• Control terminals - cables
Quick set-up
• Local Control Panel, LCP
• Automatic Motor Adaptation, AMA
• Programming
Frame size is depending on enclosure type, power range and AC line
voltage
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
Figure 3.1: Diagram showing basic installation including line
power, motor, start/stop key, and potentiometer for speed
adjustment.
