3 How to Install
3.6.15 Line power disconnectors - frame size D, E and F
Frame size
D1/D3
D2/D4
E1/E2
E1/E2
3 F3
F3
F4
3.6.16 F frame circuit breakers
Frame size
F3
F3
F4
F4
3.6.17 F frame line power contactors
Frame size
F3
F3
F3
F4
F4

3.6.18 Motor Insulation

For motor cable lengths ≤ than the maximum cable length listed in the
General Specifications tables, the following motor insulation ratings are
recommended because the peak voltage can be up to twice the DC link
voltage, 2.8 times the AC line voltage due to transmission line effects in
the motor cable. If a motor has lower insulation rating, it is recommended
to use a du/dt or sine-wave filter.
3-62
Power & Voltage
P110-P132 380–480 V & P110-P160 525–690 V
P160-P250 380–480 V & P200-P400 525–690 V
P315 380–480 V & P450-P630 525–690 V
P355-P450 380–480 V
P500 380–480 V & P710-P800 525–690 V
P560-P710 380–480 V & P900 525–690 V
P800-P1M0 380–480 V & P1M0-P1M2 525–690 V
Power & Voltage
P500 380–480 V & P710-P800 525–690 V
P630-P710 380–480 V & P900 525–690 V
P800 380–480 V & P1M0-P1M2 525–690 V
P1M0 380–480 V
Power & Voltage
P500-P560 380–480 V & P710-P900 525–690 V
P630 380–480 V
P710 380–480 V
P1M0 525–690 V
P800-P1M0 380–480 V & P1M2 525–690 V
MG.20.P3.22 - VLT
VLT AQUA High Power Instruction Manual
Type
ABB OETL-NF200A
ABB OETL-NF400A
ABB OETL-NF600A
ABB OETL-NF800A
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRK36000S20AAYP
Merlin Gerin NRK36000S20AAYP
Type
Merlin Gerin NPJF36120U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Merlin Gerin NRJF36250U31AABSCYP
Type
Eaton XTCE650N22A
Eaton XTCE820N22A
Eaton XTCEC14P22B
Eaton XTCE820N22A
Eaton XTCEC14P22B
Nominal AC Line Voltage Motor Insulation
≤ 420 V
U Standard U
N
420 V < U ≤ 500 V Reinforced U
N
≤ 600 V
500 V < U Reinforced U
N
≤ 690 V
600 V < U Reinforced U
N
®
is a registered Danfoss trademark
= 1300 V
LL
= 1600 V
LL
= 1800 V
LL
= 2000 V
LL
