VLT AQUA High Power Instruction Manual
Line Power Supply 3 x 380–480 V AC
Typical Shaft output at
400 V [kW]
Typical Shaft output at
460 V [HP]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 400 V) [A]
Intermittent (60 sec
overload)
(at 400 V) [A]
Continuous
(at 460/480 V) [A]
Intermittent (60 sec
overload)
(at 460/480 V) [A]
Continuous KVA
(at 400 V) [KVA]
Continuous KVA
(at 460 V) [KVA]
Max. input current
Continuous
(at 400 V) [A]
Continuous
(at 460/480 V) [A]
Max. cable size, line
power motor, brake
and load share [mm
(AWG 2) )]
Max. external pre-
1
fuses [A]
Estimated power loss
at rated max. load [W]
4) , 400 V
Estimated power loss
at rated max. load [W]
4) , 460 V
Weight,
enclosure IP21, IP 54
[kg]
Weight,
enclosure IP00 [kg]
Efficiency 4)
Output frequency
Heatsink overtemp.
trip
Power card ambient
trip
P110 P132
110 132
150 200
D1 D1
D1 D1
D3 D3
212 260
233 286
190 240
209 264
147 180
151 191
204 251
183 231
2 x 70 2 x 70
2 (2 x 2/0) (2 x 2/0)
300 350
3234 3782
2947 3665
96 104
82 91
185°F [85°C] 194°F [90°C]
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
6 General Specifications
P160 P200
160 200
250 300
D2 D2
D2 D2
D4 D4
315 395
347 435
302 361
332 397
218 274
241 288
304 381
291 348
2 x 185 2 x 185
(2 x 350 mcm) (2 x 350 mcm)
400 500
4213 5119
4063 4652
125 136
112 123
0.98
0–800 Hz
221°F [105°C] 221°F [105°C]
140°F [60°C]
P250
250
350
D2
D2
D4
480
528
443
487
333
6
353
463
427
2 x 185
(2 x 350 mcm)
600
5893
5634
151
138
239°F [115°C]
