6 General Specifications
Surroundings:
Enclosure, frame size D and E
Enclosure, frame size F
Vibration test
Relative humidity
Aggressive environment (IEC 721-3-3), uncoated
Aggressive environment (IEC 721-3-3), coated
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature (at 60 AVM switching mode)
- with derating
- with full output power, typical EFF2 motors
- at full continuous adjustable frequency drive output current
1) For more information on derating see the Design Guide, section on Special Conditions.
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
6 Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Derating for high altitude, see section on special conditions.
EMC standards, Emission
EMC standards, Immunity
See section on special conditions!
Control card performance:
Scan interval
Control card, USB serial communication:
USB standard
USB plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is not galvanically isolated from protection ground. Only use an isolated laptop/PC as the connection to the USB
connector on a VLT AQUA Drive or an isolated USB cable/drive.
Protection and Features:
• Electronic thermal motor protection against overload.
• Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips if the temperature reaches 203°F ± 41°F [95°C ±
5°C]. An overload temperature cannot be reset until the temperature of the heatsink is below 158°F ± 41°F [70°C ± 5°C] (Guideline - these
temperatures may vary for different power sizes, enclosures, etc.). VLT AQUA Drive has an auto-derating function to prevent its heatsink reaching
203°F [95°C].
• The adjustable frequency drive is protected against short-circuits on motor terminals U, V, W.
• If a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
• Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips if the intermediate circuit voltage is too low or
too high.
• The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
6-4
5%–95%(IEC 721-3-3; Class 3K3 (non-condensing) during operation
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
IP 00, IP 21, IP 54
-13°–+°149/°158°F [-25°–+65°/70°C]
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EN 61800-3, EN 61000-6-1/2,
USB type B "device" plug
IP 21, IP 54
0.7 g
class 3C2
class 3C3
max. 55 ° C
1)
max. 50 ° C
1)
max. 45 ° C 1)
32°F [0°C]
14°F [-10°C]
3280 ft [1000 m]
9842 ft [3000 m]
: 5 ms
1.1 (Full speed)
