Danfoss VLT AQUA Instruction Manual page 138

5 How to program the adjustable frequency
drive
6-10 Terminal 53 Low Voltage
Range:
0.07 V* [Application dependant]
6-11 Terminal 53 High Voltage
Range:
10.00 V* [Application dependant]
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
5
6-15 Terminal 53 High Ref./Feedb. Value
Range:
Application [-999999.999 - 999999.999 N/A]
dependent*
6-20 Terminal 54 Low Voltage
Range:
0.07 V* [Application dependant]
6-21 Terminal 54 High Voltage
Range:
10.00 V* [Application dependant]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
6-50 Terminal 42 Output
Option:
[0] * No operation
[100] Output freq. 0-100
[101] Reference Min-Max
5-32
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
feedback value set in par. 6-14 Terminal 53 Low Ref./Feedb. Value
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-15
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current set in
Terminal 53 Low Voltage
par. 6-10 and par. 6-12
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
Terminal 53 High Voltage
par. 6-11 and par. 6-13
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 54 Low Ref./Feedb. Value
feedback value, set in par. 6-24
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-25
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current value set in
par. 6-20 Terminal 54 Low Voltage and par. 6-22
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
Terminal 54 High Voltage
par. 6-21 and par. 6-23
Function:
Select the function of terminal 42 as an analog current output. A motor current of 20 mA corresponds
to I .
max
: 0–100 Hz
: Minimum reference - Maximum reference
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
.
Terminal 53 High Ref./Feedb. Value .
Terminal 53 Low Current
Terminal 53 High Current
.
Terminal 54 High Ref./Feedb. Value .
Terminal 54 Low Current
Terminal 54 High Current
.
.
.
.
