5 How to program the adjustable frequency
drive
5-15 Terminal 33 Digital Input
Option:
[0] * No operation
[1] Reset
[2] Coast inverse
[3] Coast and Reset Inv
[5] DC brake inverse
[6] Stop inverse
[7] External interlock
[8] Start
[9] Latched start
5
[10] Reverse
[11] Start reverse
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Slow
[23] Set-up select bit 0
[24] Set-up select bit 1
[30] Counter input
[32] Pulse input
[34] Ramp bit 0
[36] Mains failure inverse
[37] Fire Mode
[52] Run permissive
[53] Hand start
[54] Auto-start
[55] DigiPot increase
[56] DigiPot decrease
[57] DigiPot clear
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[66] Sleep Mode
[78] Reset Maint. Word
5-26
Function:
Same options and functions as par. 5-1* Digital Inputs.
®
