3 How to Install
3
Figure 3.40: Position of ground terminals IP00, frame sizes
D
NOTE!
D2 and D4 shown as examples. D1 and D3 are equivalent.
3-46
Figure 3.41: Position of ground terminals IP21 (NEMA type
1) and IP54 (NEMA type 12)
®
MG.20.P3.22 - VLT
is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
