1.3 Down Converter Features

1.3.1

Physical Description

The DT-4500 features a 1RU-high (1.75") 19-inch wide chassis that is designed
for rack mounting into a standard 19-inch (48.26 cm) equipment rack. The unit
may also be mounted into the rack using the provided slide mechanisms to allow
service without removal from the rack. The unit may be freestanding if desired.
For:
Rack installation and
•
mounting instructions
Local control operating
•
instructions and procedures
Remote control operating
•
instructions and procedures
Redundant system operating
•
instructions and procedures
Maintenance and
•
troubleshooting procedures
See:
Chapter 3. INSTALLATION
Chapter 6. FRONT PANEL
OPERATION
Chapter 7. ETHERNET INTERFACE
OPERATION and
Chapter 8. SERIAL INTERFACE
OPERATION
Appendix A. REDUNDANT
SYSTEM OPERATION
Appendix B. MAINTENANCE
TROUBLESHOOTING
