3.4.1 Save Operation

3.4.2 Recall Operation

3.5 Data Logging Function

Category Parameter
OCP/OVP/OPP/UCP/UVP delay time: Delay
UCP/UVP warm-up time: Warm-up
You can do the save and recall operations by the following two methods.
•
Press the composite keys [Shift]+[+/-] (Save) to save the parameters. Press
the [Recall] key to recall the parameters.
•
SCPI commands: *SAV and *RCL
The save operation procedures are as follows:
1. Press the composite keys [Shift]+[+/-] (Save) to enter the parameter save
interface.
2. Set the storage location.
Enter a number in the "Save data to bank=0" to set the storage location in
non-volatile memory.
3. Press [Enter] to save the parameters.
You can recall the parameters you saved in the specified memory location as
the setting values.
1. Press the [Recall] key to enter the parameter recall interface.
2. Set the storage location.
Enter a number in the "Recall data from bank=0" to set the storage location
in non-volatile memory.
3. Press [Enter] to recall the parameters.
The IT6000C series Bi-directional Programmable DC Power Supply supports
the recording and saving of test data. This Chapter introduces how to use this
function in details.
