Pins Introduction
Maximum low level input
voltage
Typical high level output
voltage
Typical low level current
Minimum high level input
voltage
Level rise slope
Level fall slope
The appearance of the terminals are shown below.
Pin Description
1 Corresponds to the function set in the
System→Digital Port→IO–1. Ps-
Clear, Not-Invert menu item. For pa-
rameter introduction, see
1. Ps-Clear, Not-Invert.
2 Corresponds to the function set in the
System→Digital Port→IO–2. Ps,
Not-Invert menu item. For parameter
introduction, see
Not-Invert.
3 Corresponds to the function set in the
System→Digital Port→IO–3. Off-
Status, Not-Invert menu item. For
Copyright © Itech Electronic Co., Ltd.
1
0.8V
5V
0V
1.6V
10us
2us
Properties
(Default
function)
Pulse signal
3.6.7.1 IO–
Level signal
3.6.7.2 IO–2. Ps,
Level signal
www.tehencom.com
Basic Operation
100
0.5mA
Properties
(General I/O
function)
Level or PWM
signal
Level or PWM
signal
Level or PWM
signal
