Start Data Logging

3.6 System Menu Function

Before this operation, make sure to connect the USB memory device
to the memory port on the front panel (The USB interface on the rear
panel can only be used for connecting the PC) so that the recorded
data can be stored in the external storage device. Otherwise, the Data
Recording function is not available for usage.
•
Manual
Press the composite button [Shift] + [On/Off] (Trigger) on the front panel to
trigger.
•
Bus
Triggered by the SCPI instruction, for example, when the instrument re-
ceives the trigger command *TRG, a trigger operation is performed.
•
External
Connect to pin 4 of the digital I/O interface (P-IO) and set pin 4 to Ext-Trig→-
Trig-In→Dlog to trigger.
For details, see 3.6.7.4 IO–4. Ext-Trig,
After the data recording function is started, the lower right corner of the main in-
terface displays Logging, indicating that the data is recorded. The recorded da-
ta is saved in USB memory device in .csv format. The user can get access to
these files for analysis based on needs.
This Chapter offers a general introduction of system menus, allowing users to
have a preliminary understanding of system functions of this IT6000C series.
The steps of the system menu function are as follows:
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
At this point, the VFD screen displays the system menu items. Each menu
item has a numbering identifier. The user can press Up and Down buttons or
use the knob for scrolling display of other menu items.
2. Press [Enter] on a menu interface to enter the setting interface.
