Stop the Vehicle Waveform Running
4.6.3.1 Automotive Starting Waveform
The trigger method of the vehicle waveform is consistent with the trigger
method of the List function, that is, the List trigger source is also effective for
the vehicle waveform.
If you want to stop during the vehicle waveform output, you can do the following:
Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter
the function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion (FUNCTION STOP?), you can press the Left/Right key to select Yes, then
the current running will be stopped, and the Function menu item will be dis-
played, you can re-enter the Function menu for editing; if No is selected, it
means that the current running will not be stopped, and the main interface of the
system is displayed.
The IT6000C series power supply has built-in 12V or 24V DIN40839 waveform.
This test verifies the behavior of a DUT during and after cranking. This wave-
form can reproduce the voltage curve for automotive power network confirms to
DIN40839 standard, thus facilitating quick call by customers.
For automotive startup voltage waveform, the startup voltage can also be set
based on customers' requirements. In this way, the user can create waveform
between 8V to 32V.
Evaluation of automotive starting
DIN40839
waveform
12V
24V
User-defined
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
Select the automotive
starting waveform with
a starting voltage of
12V.
Select the automotive
starting waveform with
a starting voltage of
24V.
The user customizes
the starting voltage of
the automotive starting
waveform.
