as for the IP Address. A value of 0.0.0.0 indicates that no default server is
defined.
•
Socket Port: This value indicates the port number corresponding to the
service.
Serv-Conf
Configurable services include: MDNS, PING, Telnet-scpi, Web, VXI-11, and
Raw Socket.
How to Configure
•
IP-Conf
Take manual configuration as an example. The steps are as follows:
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to
enter the system menu.
2. Rotate the knob or press the Up/Down key to select 6. I/O Con and press
[Enter].
3. Press the Left/Right key to select LAN and press [Enter].
4. Press the Left/Right key to select IP-Conf and press [Enter].
5. Press the Left/Right key to select Manual and press [Enter].
6. Set the IP Addr, SubNet and the other parameters in turns, and press
[Enter].
After the last parameter Socket Port is set, the system will return to the
LAN setting interface shown as below:
SYSTEM I/O CONF
Info IP-Conf
7. Press the Left/Right key to select Reset to confirm the settings of IP-
Conf.
•
Serv-Conf
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to
enter the system menu.
2. Rotate the knob or press the Up/Down key to select 6. I/O Con and press
[Enter].
3. Press the Left/Right key to select LAN and press [Enter].
4. Press the Left/Right key to select Serv-Conf and press [Enter].
5. Rotate the knob to select the service you want to enable and press
[Enter].
Copyright © Itech Electronic Co., Ltd.
Remote Interface Connection
LAN
Serv-Conf Reset
